DESCRIPTION

Works Hard. Rides Smooth.
Unmatched comfort for the to-do list and the trail.

HIGHLIGHTS

• A smooth ride ready for the next job or off-road journey.
• Electric Power Steering
• Double A-Arm Front and Rear Suspension
• Class-Leading 10-inch Front and Rear Travel
• 1,050-lb Towing Capacity
• 545cc Liquid-Cooled Single-Cylinder Closed-Loop EFI Engine
• 11-inch Ground Clearance
• Standard Accessories: Steel Front and Rear Rack, Standard Front Bumper, Standard Front Tow Hook

FEATURES

• Double A-Arm Front and Rear Suspension: A full-size chassis loaded with class-leading 10-inch front and rear travel and adjustable front shock absorbers — so you don’t have to back down when the trail gets rough.
• 1,050-lb Towing Capacity: Pull over half a ton with a front tow hook and 2-inch rear receiver.
• EFI Engine: A ready-to-ride, 545cc liquid-cooled single cylinder engine puts a damper on loud engine noise and improves fuel efficiency.
• 11-inch Ground Clearance: A higher center of gravity, so you can take on all the rough terrain you can find.
• Electronic Power Steering: Take command of the trail with standard EPS for easy, responsive steering.
• 25 Inch Tires: Lightweight and ready to handle a variety of conditions.
• 12-Month Warranty: A year of rock-solid coverage so you can have peace of mind on the trail.

ENGINE & DRIVETRAIN

• Engine Type: Liquid-Cooled, Single Cylinder Single Overhead Cam, Gas Engine
• Displacement: 545cc
• Drive Train: CVT
• Drive System: RTS (Rapid Traction System)
• Engine Braking System: Standard
• Fuel System: Electronic Fuel Injection (EFI)
• Gear Selection: H,L,N,R,P
• Front Differential: 2WD/4WD Differential
• Rear Differential: Spool

STEERING & SUSPENSION

• Steering: Electronic Power Steering
• Front Suspension: Double A-Arm with 10 in. (25 cm) Travel
• Rear Suspension: Double A-Arm with 10 in. (25 cm) Travel
• Brake System: Single Lever Front, All Wheel Hydraulic Disc
• Foot Brake: Hydraulic Rear
• Parking Brake: Park in Transmission
• Front Tires: 25 x 8 - 12
• Rear Tires: 25 x 10 - 12
• Wheels: Steel

PERFORMANCE

• Total Capacity: 515 lbs (233.6 kg)
• Front Rack: 100 lbs (45.3 kg)
• Rear Rack: 200 lbs (90.7 kg)
• Towing Capacity: 1,050 lbs (476 kg)

DIMENSIONS

• Overall Length: 83.4 in. (212 cm)
• Overall Width: 48.5 in. (123 cm)
• Overall Height: 49.5 in. (125.7 cm)
• Overall Weight: 699 lbs (317 kg) (Dry)
• Wheel Base: 52 in. (132 cm)
• Ground Clearance: 11 in. (28 cm)
• Fuel Capacity: 5.7 gal (21.6 L)
• Hitch: Standard/2 in. (5 cm) Receiver

COLOR OPTIONS

• Skid Plate: Standard
• Standard Colors: Dynamic Charcoal

ADDITIONAL FEATURES

• Standard Instrumentation: Digital Gauge, Speedometer, Odometer, Tripmeter, RPM, Gear Indicator, Fuel Gauge, Low Fuel Warning, Clock, High Beam, Air Intake Temp, Coolant Temp, Coolant Temp Warning, Battery Voltage, Hour Meter
• Lighting: Dual Beam Headlights, Dual Brake Lights/Taillights
• Start Method: Electric Start
• Standard Accessories: Steel Front and Rear Racks, Standard Front Bumper, Standard Front Tow Hooks
